| RFID Protocol | EPC Class1 Gen2, ISO18000-6C |
| Frequency | US 902-928MHz, EU 865-868MHz |
| IC type | NXP UCODE 8 |
| Memory | EPC 128bits , USER 0bits, TID 96bits |
| Write Cycles | 100,000times |
| Functionality | Read/write |
| Data Retention | Up to 50 Years |
| Applicable Surface | Metal Surfaces |
| Read Range(On Metal) : (Fix Reader) |
Up to 11.0m - (US) 902-928MHz, on metal Up to 10.0m - (US) 865-868MHz, on metal |
| Read Range(On Metal) : (Handheld Reader) |
Up to 5.5m - (US) 902-928MHz, on metal Up to 5.0m - (US) 865-868MHz, on metal |
| Warranty | 1 Year |
| Physical Specification: |
| Size | 105x30mm, (Hole:D5.2mmx2) |
| Thickness | 7.5mm |
| Material | ABS+PC |
| Colour | White |
| Mounting Methods | Magnet |
| Weight | 30g |
| Grade | N48 |
| Gauss magnetic force | 3300 Gaus |
| Enivironmenal Specification: |
| IP Rating | IP68 |
| Storage Temperature | -40°C to +70°C |
| Operation Temperature | -25°C to +70°C |
| Certifications | Reach Approved,RoHS Approved,CE Approved |
