UHF Flexible RFID Label

A general-purpose UHF RFID label in four facestocks — coated paper, PET, PP synthetic paper or thermal paper — so one 73.5 × 21.2 mm format covers cartons, waybills and warehouse shelves. Alien-H9 or Monza-m4qt, 905–928 MHz, IP68, ≥8 m on a handheld and ≥12 m on a fixed reader.

CategoryRFID 柔性标签
Views1,205
Total Sold670,893
SpecificationCoated paper facestock, thermal transfer, Alien-H9, unprinted / PET facestock, weather-resistant, Monza-m4qt, custom print
Price联系询价
Download Specification
ItemSpecificationNote
协议EPC Class 1 Gen 2; ISO 18000-6CStandard Gen 2 readers
Frequency905–928 MHzCN and US bands
ChipAlien-H9 or Monza-m4qtSelected at order
内存96 or 128-bit EPC; 512-bit userUser block for item data
尺寸73.5 × 21.2 mmLabel face
FacestockCoated paper / PET / PP synthetic paper / thermal paper下单时选择
AdhesivePermanentClean dry surface required
颜色White支持定制彩色印刷
重量0.5 g按标签
应用表面Non-metal纸板、塑料、纸张
Read range, handheld≥8 米,在 2 W ERP、1 W 发射功率下,0–3 dBiIn air
Read range, fixed reader≥12 米,在 4 W ERP、4 W 发射功率下,6–12 dBiIn air
防护等级IP68防尘,防水
工作温度-40 至 85 °C存储温度:40 至 105 °C
打印Thermal transfer, direct thermal or laserDepends on facestock

Facestock selection table

FacestockPrint method最佳用途Watch out for
Coated paperThermal transfer, laserIndoor cartons, shelf labels, short-life goods最低防潮等级
聚对苯二甲酸乙二醇酯Thermal transferOutdoor goods, washdown, long-life assetsHighest cost of the four
PP synthetic paperThermal transferDamp warehouses, tear-resistant ticketsInk needs the right ribbon
Thermal paperDirect thermalWaybills, parcel labels, fast print runsPrint fades with heat and light

Factory inspection sheet

Check验收标准Action if out of spec
Read testReads on a handheld reader at the near end of the bandReject the label
模切尺寸Within the agreed label tolerance, liner cleanly cutRe-cut or scrap
Print registrationArtwork and barcode inside the print area, clear of the inlay edge重新打印或报废
Adhesive tackNo corner lifting after application to test boardReject the roll
EncodingWritten EPC matches the supplied data rangeRe-encode or scrap

Application scenarios

Retail and warehouse carton labels

Cartons are labelled as they are packed, with the EPC written at the printer so the box is traceable from the packing bench onwards. A coated paper or thermal paper stock is enough indoors, and the 73.5 × 21.2 mm face leaves room for a barcode beside the RFID inlay.

Label printer producing white RFID labels for cartons

Logistics waybills and parcel labels

Parcel and pallet paperwork carries the same label format, so a waybill and its carton can be scanned in one pass at the dock. Thermal paper prints fastest for daily volumes; PET is the choice when labels ride on the outside of a vehicle or sit in the rain.

Printed white UHF parcel labels with barcodes

Warehouse carton flow and turnover crates

在传送带或转运线上,当纸箱经过固定阅读器时,标签会以高速被读取,这正是 ≥12 米读距的价值所在。标签贴于纸箱堆叠中始终朝外的面上,因此整托盘无需旋转即可被完整读取。

Cartons moving along a conveyor in a warehouse

One format, four facestocks

UHF 柔性 RFID 标签尺寸为 73.5 × 21.2 mm,提供四种面材:涂布纸、PET、PP 合成纸和热敏纸。单一天线规格即可适用于纸箱、运单、零售吊牌及仓库货架,无需为不同场景定制新标签。所有版本均采用 Alien-H9 或 Monza-m4qt 芯片封装,手持设备读取距离≥8 m,固定读写器读取距离≥12 m。

The facestock is what you actually choose when you order: it decides the printing method, how the label survives damp or abrasion, and how much it costs per thousand.

Sheet and roll of white UHF flexible RFID labels

Choosing the facestock: four questions

确定价格前请先完成以下步骤,因为最便宜的供应商未必能胜任工作。

  • How is the label printed? Thermal paper suits direct thermal printers; coated paper, PET and PP take thermal transfer ribbons or laser printing.
  • Will it get wet or rubbed? Paper stocks smear under moisture and abrasion; PET and PP hold up far better on outdoor or washdown goods.
  • What is it being stuck to? All four are non-metal labels; on bare steel or aluminium use an on-metal product instead.
  • What is the cost per thousand? Coated paper is the cheapest base, PET the most durable, PP a middle ground that prints well and resists tearing.

两张印有二维码的白色 UHF 标签平放在白色表面上

打印与编码

The label is supplied blank, or printed with your artwork, barcode or serial range, and it can be encoded with an EPC value during production so the roll arrives ready to apply. Keep the print area off the very edge of the antenna, because heavy ink coverage over the inlay can cost a little read range.

Thermal transfer gives the most durable print on PET and PP; direct thermal on thermal paper is cheaper but fades with heat and light. If the labels will sit in a sunny yard for months, print on PET rather than thermal paper.

Desktop label printer loaded with a roll of UHF RFID labels

Read range and where it comes from

At 73.5 × 21.2 mm the antenna is large enough for long-range reads: ≥8 m with a 1 W handheld at 2 W ERP, and ≥12 m with a 4 W fixed reader behind a 6–12 dBi antenna, measured in air on a non-metal surface. On a pallet of cartons the outer layer reads easily; the boxes buried in the middle of the stack read only when the stack is broken or the reader is worked around it.

Thermal label printer producing blank white RFID labels

When to move to another label

If the asset is steel, go to a flexible on-metal label; if the label must prove tampering, go to a fragile label. For cardboard, plastic and paper surfaces this format is the general-purpose default, and the four facestocks cover almost every printing and durability requirement within it.
