| Item | Specification | 备注 |
|---|---|---|
| Chip | NTAG213 | NFC Forum Type 2 |
| 协议 | ISO/IEC 14443A | 13.56 MHz read and write |
| Frequency | 13.56 MHz(高频) | — |
| 用户内存 | 144 bytes | NDEF formatted at delivery |
| UID | 7 bytes, factory programmed | Read-only |
| 尺寸 | Ø25 毫米 | Other die-cut shapes on request |
| Face material | Coated paper / PET / PP synthetic paper / thermal paper | Selected per application |
| Adhesive | Permanent acrylic, single side | Apply on clean, dry, non-metal surface |
| 打印 | Up to 4-colour flexo or digital | Variable data in the same pass |
| 读取距离 | 1–10 mm(固定读取器) | Depends on reader output and antenna |
| Weight | 0.5 克 | 按标签 |
| 防护等级 | IP68 | On non-metal surfaces, adhesive intact |
| 工作温度 | -40 至 +85 °C | — |
| 存储温度 | -40 至 +105 °C | — |
| 打包 | Roll or sheet | 格式按订单约定 |
面料材质与编码按应用场景分类
| 应用场景 | Face material | 编码 | Why |
|---|---|---|---|
| Indoor poster behind glass | Coated paper | NDEF URL | Lowest cost face that still prints sharp |
| Table sticker in a cafe | PP synthetic paper | NDEF URL with table code | Wipeable and tear resistant |
| Product pack and carton | 聚对苯二甲酸乙二醇酯 | UID 列表加二维码 | Holds print on curved packs, UID cannot be copied by reprinting |
| Batch label printed on site | Thermal paper | Fixed text or serial | Printed at the point of use, no plate needed |
| Exhibition guide point | Coated paper or PET | NDEF URL, locked | Record must not be changed by a visitor |
Inspection before packing
| Check | Pass criteria | 失败时操作 |
|---|---|---|
| Read test | 手机和固定读卡器首次触摸时读取标签 | Remove the label from the roll |
| NDEF 内容 | Matches the order file character for character | Re-encode; scrap if the write fails twice |
| Die-cut size | Within ±0.2 mm of the approved drawing | Re-cut or scrap the batch |
| Print registration | No colour offset visible at 1:1 | Re-print |
| 可撕胶条 | 从离型纸上剥离,无残留转移 | Replace the liner roll |
Application scenarios
店内海报与桌贴
A poster in the window or a sticker on the table corner is the cheapest place to add a tap point, because the customer is already looking at the offer. The label opens the campaign page or the digital menu, and a per-label code shows which surface was actually touched. Use PP synthetic paper where drinks spill; coated paper is fine behind glass.

Product authentication and instructions
On a product or its carton the label confirms the batch and opens the setup or care instructions. The UID gives each item a unique reference without a printed serial, so support can identify the unit from the tap alone. Keep the label on a flat, non-metal area of the pack.

展览与导览要点
Museums, show homes and trade stands use the label as a guide point: one tap opens the room description, the specification sheet or a booking form. It can be die-cut to a small round or square format and printed to match the panel, so the tap point disappears into the display. The visitor's own phone does the work, with no fixed reader on site.
