柔性抗金属 RFID 标签
柔性抗金属 RFID 标签
柔性抗金属 RFID 标签
柔性抗金属 RFID 标签
+

柔性抗金属 RFID 标签

一款柔性 PET 金属表面 UHF 标签,在钢面上仍能保持读取距离:90 × 40 × 2.2 mm,Alien-H9 或 Monza-m4qt, 905–928 MHz,IP68,手持设备读取距离 ≥5.5 m,固定阅读器读取距离 ≥7 m,背胶可贴合曲面金属。

CategoryRFID 柔性标签
Views409
Total Sold262,739
SpecificationStandard 90 × 40 mm PET, Alien-H9, white unprinted / Custom printed PET, Monza-m4qt, colour logo and zone coding
Price联系询价
Download Specification
ItemSpecificationNote
协议EPC Class 1 Gen 2; ISO 18000-6CStandard Gen 2 readers
Frequency905–928 MHzCN and US bands
ChipAlien-H9 or Monza-m4qtSelected at order
内存96 or 128-bit EPC; 512-bit userUser block for asset codes
尺寸90 × 40 × 2.2 毫米附带金属垫片
FacestockPET, flexibleFollows curved metal
AdhesivePermanent, high tackClean dry surface required
颜色White支持定制彩色印刷
重量1.5 g按标签
应用表面MetalSteel, aluminium, painted metal
Read range, handheld≥5.5 米,在 2 W ERP、1 W 发射功率下,0–3 dBiOn metal surface
Read range, fixed reader≥7 米,在 4 W ERP、4 W 发射功率下,6–12 dBiOn metal surface
防护等级IP68防尘,防水
工作温度-40 至 85 °C存储温度:40 至 105 °C
安装背胶Press from centre outwards

将标签与安装方式匹配

Mounting situationRecommended approachExpectation
Flat steel plate or cabinet sideStandard 90 × 40 mm label, flatQuoted range applies
Drum, pipe or rounded housingLabel along the curve, pressed flatSlight loss on tight radii
Painted or powder-coated steelClean and degrease, then applyQuoted range if coating is sound
Non-metal carton or plastic binStandard flexible label insteadLower cost for the same read

Factory inspection sheet

Check验收标准Action if out of spec
金属内读取测试Reads at the near end of the band on a steel plateReject the label
Off-metal comparisonNo sharp detuning drop against the reference sampleHold the batch
Dimensions and thicknessWithin the agreed tolerance, spacer intactRe-cut or scrap
Adhesive tackNo corner lifting after application to a coated test panelReject the roll
表面光洁度No bubbles, creases or glue bleedReject the label

Application scenarios

Metal racks and storage bins

Racking bays and steel bins are labelled at the beam or on the bin face, so a stock take reads the storage location as well as the goods. Because the label tolerates the steel behind it, a handheld pass down the aisle returns every bay without walking to each one.

钢制仓库货架,存放纸箱货物

钢桶和气体钢瓶

Drums, kegs and cylinders are identified on the body, where a standard label would be detuned by the steel wall behind it. The flexible face follows the barrel curve, and the IP68 rating keeps the label working through outdoor storage and washdown.

Plain steel drum ready for asset labelling

机箱与设备外壳

Machine frames, motor housings and cast parts carry the label as a maintenance and warranty identifier, often next to a stamped serial number. The 2.2 mm face bridges small surface irregularities, and the read survives the oil and dust of a working plant floor.

固定在铸造机外壳上的抗金属标签

Why a label on steel reads differently

柔性抗金属 RFID 标签为 90 × 40 × 2.2 mm PET 材质,其内置芯片针对金属表面优化,确保在标准 UHF 标签因贴附于金属表面而失效时,仍能保持有效读取距离。该标签采用背胶设计,可牢固粘贴于钢、铝及涂漆金属表面,并随安装面板弯曲贴合。

这使得它成为金属资产的理想选择,如货架、鼓桶、机器外壳、机柜以及仓库和工厂中的喷漆钢板。

白色柔性抗金属 RFID 标签卷

Four variables that decide the real read range

The figures on the specification sheet are measured in air on a metal surface; on site, four things move the number up or down.

  • The surface itself: a thick steel plate detunes differently from thin sheet, and bare metal differs from a powder-coated panel.
  • Label area:更大的天线能捕获更多能量,因此 90 × 40 毫米的标签在相同功率下比小型金属表面标签表现更优。
  • 间距与曲率: the label needs to sit flat; if it bridges a weld seam or a deep emboss, part of the antenna lifts and range falls.
  • 读卡器电源与天线: the quoted ≥5.5 m uses a 1 W handheld at 2 W ERP; a 4 W fixed reader with a 6–12 dBi antenna reaches ≥7 m.

实际部署前,请先在目标资产上测试单个标签,再确定安装高度或阅读器布局。

Steel drum with a flexible anti-metal label attached to its side

在曲面和涂漆金属上安装

The PET face is flexible enough to follow a drum, a pipe or a rounded housing, but it should be pressed down from the centre outwards so no air is trapped under the antenna. On a curved surface, orient the label along the curve rather than across it, so the long edge bends instead of buckling.

施贴前请清洁表面:新钢材上的油膜和脱模剂是导致标签几周后边角翘起的常见原因。在粉末涂层面板上,粘合剂是粘附于涂层而非钢材,因此涂层必须完好无损。

Anti-metal RFID label applied to a cast metal machine part

What the label is made of

The facestock is white PET at 2.2 mm overall, including the on-metal spacer, and the label weighs 1.5 g. It is rated IP68 and works from -40 to 85 °C, with storage to 105 °C, so washdowns and outdoor yards are within spec. Custom colour printing is available when the label needs to carry a logo or a zone colour.

Metal warehouse racking holding cartons, a typical anti-metal labelling environment

Where it is the wrong choice

On cardboard, plastic or timber, a cheaper standard label reads at least as well and costs less. Above 85 °C in operation, or on a surface too tightly curved for a 90 mm face, a rigid on-metal tag or a high-temperature tag is the better starting point. For tamper evidence rather than metal tolerance, use a fragile label instead.
